6 CONTROLS 27
6.9 Ignition/steering lock
600825-01
The ignition/steering lock
is located in front of the seat.
Possible states
Ignition OFF – In this position, the ignition circuit is interrupted, a running
engine stops, and a non-running engine will not start. The ignition key can
be removed.
Ignition ON – In this position, the ignition circuit is closed and the engine
can be started.
Steering locked – In this position, the ignition circuit is interrupted and the
steering locked. The ignition key can be removed.
6.10 Combination instrument
6.10.1 Overview
401420-10
The combination instrument is installed in front of the handlebar.
The combination instrument is divided into 4 function areas.
Function buttons
Tachometer
Indicator lights
Display
