22 TECHNICAL DATA 176
Comfort 25 clicks
Standard 20 clicks
Sport 15 clicks
Full load capacity 15 clicks
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
Spring preload 20 mm (0.79 in)
Spring rate
Medium (standard) 80 N/mm (457 lb/in)
Hard 85 N/mm (485 lb/in)
Spring length 220 mm (8.66 in)
Gas pressure 10 bar (145 psi)
Static sag 20… 25 mm (0.79… 0.98 in)
Riding sag 70… 80 mm (2.76… 3.15 in)
Fitted length 395 mm (15.55 in)
Shock absorber fluid Shock absorber oil (SAE 2.5) (50180342S1) ( p. 183)
22.9 Chassis tightening torques
Screw, chain guard EJOT 2 Nm (1.5 lbf ft) –
Screw, combination instrument EJOT 1 Nm (0.7 lbf ft) –
Screw, license plate holder, bottom EJOT 3 Nm (2.2 lbf ft) –
