17 SERVICE WORK ON THE ENGINE 144
100200-10
– Place a suitable container under the engine.
–
Remove the oil drain plug
with the magnet and seal ring.
– Completely drain the engine oil.
100201-01
– Thoroughly clean the oil drain plug with a magnet.
– Mount the oil drain plug with the magnet and seal ring and tighten it.
Guideline
Oil drain plug with magnet M12x1.5 20 Nm
(14.8 lbf ft)
17.4 Removing the oil filter x
Warning
Danger of scalding Engine oil and gear oil get very hot when the motorcycle is ridden.
– Wear appropriate protective clothing and safety gloves. In case of burns, rinse immediately with lukewarm water.
