6 CONTROLS 24
6.5 Start button
C00793-11
The start button
is fitted on the right side of the handlebar.
The start button is only enabled when the main switch is switched on.
When the start button is pushed, the vehicle switches from standby to ready mode. The
driving mode indicator and an acoustic signal indicate operating readiness.
When the start button is pushed again, the vehicle switches back to standby mode. The
driving mode indicator goes out.
Info
Standby mode can only be switched to ready mode if the throttle grip is fully
closed and the vehicle speed is less than 5 km/h. If the vehicle is not moved
for 90 seconds after ready mode is activated and the throttle grip is not twisted
open, the vehicle automatically switches back to standby mode.
Possible states
• The start button is in the neutral position – The state of the vehicle is retained.
• The start button is pressed – The state of the vehicle changes between ready mode
and standby mode.
6.6 Horn button (Freeride E‑XC)
C00822-10
The horn button
is fitted on the left side of the handlebar.
Possible states
• Horn button in neutral position
• Horn button pressed – The horn is operated in this position.
6.7 Light switch (Freeride E‑XC)
C00823-10
The light switch
is fitted on the left side of the handlebar.
Possible states
Low beam on – Light switch is in the central position. In this position,
the low beam and tail light are switched on.
High beam on – Light switch is turned to the left. In this position, the
high beam and the tail light are switched on.
6.8 Turn signal switch (Freeride E‑XC)
C00822-11
Turn signal switch
is fitted on the left side of the handlebar.
Possible states
Turn signal light off – Turn signal switch is in the central position.
Turn signal light, left, on – Turn signal switch is turned to the left.
Turn signal light, right, on – Turn signal switch is turned to the right.
