11. - Troubleshooting guide
GMD240 - 280 - 310
105
KN204BGB_G
Disc mower
Stubble too long. Incorrect cutter bar pitch
angle.
- Modify pitch angle using
top link.
Machine too light. - Adjust compensating
spring tension.
- Check frame position.
Too frequent safety
breakback release.
Insufficient spring washer
compression.
- Increase spring washer
compression.
Insufficient ground
clearance in headland turn
position.
The headland turn position
valve shuts off too early.
- Adjust limiter adjustment
screw.
