KUHN GMD310 - Spring Plate Replacement

GMD240 - 280 - 310
100
10. - Maintenance and storage
KN204BGB_G
Disc mower
- Position conical centre of spring washer at the top.
- Tighten screws:
• Torque: 12.3 daNm (91 lbf ft).
10.3.6 Spring plate replacement
- Remove the disc:
- See section: Maintenance and storage /
Maintenance / Disc replacement.
- Remove spring plate (1).
- Refit the disc:
- See section: Maintenance and storage /
Maintenance / Disc replacement.
+
+
+
+
+
+
+
+
+
1
