10. - Maintenance and storage
GMD240 - 280 - 310
99
KN204BGB_G
Disc mower
Disc replacement
- Place a wooden wedge (2) between two discs to
stop them from moving.
- Remove 2 bolts (1) and their spring washers using
the box spanner supplied with the machine.
- Remove the disc conical cover.
- Remove the 2 screws (1) and their spring washers.
- Remove the disc (2).
When remounting:
- Position their largest diameters at right angles to
each other.
