10. - Maintenance and storage
GMD240 - 280 - 310
85
KN204BGB_G
Disc mower
10.3.3 Check angle gearbox oil level
- Regularly check the oil level:
- Place the cutterbar in horizontal position.
- Remove drain plug (1) and its washer.
- Check the oil level: The oil level must reach the
lower edge of the emptying hole (1).
- Top up if necessary.
- Clean and reinstall drain plug (1) and its washer.
Replace if necessary.
10.3.4 Breather plug checking and cleaning
From the working position:
- Remove breather plug (1) and its seal.
- Clean and check breather plug for good
functioning (1).
- Reinstall breather plug (1) and its seal.
1
2
1
