GMD240 - 280 - 310
46
6. - Putting into service
KN204BGB_G
Disc mower
When the following equipment is fitted:
Mechanical safety release + Hydraulic pivot +
Lighting and signalling
- Connect the hydraulic hoses for the mechanical
safety release with hydraulic pivot to the
additional double acting valve.
6.2.6 Electrical connection
When optional equipment is used, follow specific
procedures mentioned in the related section:
- Optional equipment / Lighting and
signalling.
6.2.7 Primary PTO shaft
Before using the machine for the first time:
- Grease the transmission.
• Check overlap of the u-joint drive shaft
and adjust length if necessary to avoid
any premature wear.
The direction of rotation is shown on a decal.
- The tractor PTO must rotate at a speed of 540/min.
- Separate the two half PTO shafts and connect
them to the machine's input shaft and to the tractor
PTO stub.
- Check the length of the PTO shaft:
- When extended to the maximum, the tube overlap
must not be below 250 mm (10’’).
