6. - Putting into service
GMD240 - 280 - 310
47
KN204BGB_G
Disc mower
If this is not the case:
- Mark length (H) to cut when the transmission is the
maximum overlap position.
- Shorten the guard tubes and the transmission
tubes by the same length.
- Bevel and clean the tubes.
- Grease the inside of the outer tube.
- Never operate the PTO shaft at an angle X
exceeding 30°.
To avoid serious accidents, the PTO drive
shaft guards must be properly in place and
fixed with the chains provided.
- Attach PTO shaft guard chain in hole (1) on
machine side.
- Immediately replace any worn or damaged
guard.
