6. - Putting into service
GMD240 - 280 - 310
41
KN204BGB_G
Disc mower
Machines fitted with a 540 min-1 central
gearbox must be driven by a power-take-off
rotating at 540 min-1.
- Select the speed of 540 min-1 inside the tractor.
When the following equipment is fitted:
• Mechanical safety release
The tractor must be fitted with a single acting
hydraulic outlet with float position.
or
When the following equipment is fitted:
Mechanical safety release + Hydraulic pivot +
Lighting and signalling
The tractor must be fitted with a double acting
hydraulic outlet.
The tractor must be fitted with a single acting
hydraulic outlet with float position.
Hitch pin parallelism
- Adjust tractor lift rods so that hitch pins are parallel
to the ground.
