8. - Instructions for work
GMD240 - 280 - 310
55
KN204BGB_G
Disc mower
When the following equipment is fitted:
Mechanical safety release
- Place the single acting valve of the mowing unit
lift cylinder in floating position to fully lower the
mowing unit.
- Lower the tractor lift linkage in working position.
- Unlock and lower the front guard using 18 box
spanner supplied with the machine.
• The guard locks automatically.
When the following equipment is fitted:
Mechanical safety release + Hydraulic pivot +
Lighting and signalling
- Place the single acting valve of the mowing unit
lift cylinder in floating position to lower the
mowing unit until the end of the mowing unit is
approx. 500 mm (1’8’’) from the ground.
- Activate double acting valve of pivot cylinder to
fully pivot the machine frontwards.
- Place the single acting valve of the mowing unit
lift cylinder in floating position to fully lower the
mowing unit.
- Lower the tractor lift linkage in working position.
