10. - Maintenance and storage

GMD240 - 280 - 310

KN204BGB_G

Disc mower

 Securing elements

- Check the securing elements:

• After hitting an obstacle.

• When replacing knives.

• At the beginning of each season.

GMD240

GMD280

GMD310
