10. - Maintenance and storage
GMD240 - 280 - 310
91
KN204BGB_G
Disc mower
- Check if there is still a minimum gap X = 1
mm (0.04’’) between the disk lower part and
the cutter bar wear plates.
- If this is not the case, fit one (maximum
two) spacer(s) between the disc and the
mounting hub.
When the following equipment is fitted:
- Fast fit knives
