Kyocera ECOSYS P4060DN User Manual

10-22
Troubleshooting > Troubleshooting
5
Start up the browser.
Enter "https://" and host name of the machine to access the Command Center RX.
6
Select [Device Information/Remote Operation] > [Remote
Operation].
7
Click [Start] button.
When the Remote Operation is started up, the operation panel screen will be displayed on the
system administrator's or user's PC screen.
Executing Remote Panel from VNC Software
1
Display the screen.
[System Menu/Counter] key > [System/Network] > [Network] > [Protocol Settings]
2
Set "Enhanced VNC (RFB)" to [On].
3
Startup the remote operation.
1 Start up the VNC software.
2 Enter the following format separated by a colon to start up the remote operation.
"IP address: port number"
Accessing Command Center RX (page 2-52)
NOTE
• If the user is logged in to the device, the permission confirmation screen will be displayed
on the operation panel. Select [Yes].
• If pop-up blocking of the browser occurs during connection of the Remote Operation,
select Always allow pop-ups from https:// [host name], and click Done. Perform Remote
Operation after waiting 1 minute or more.
Protocol Settings (page 8-37)
NOTE
• When setting "VNC (RFB) over SSL" to [On], the communication is encrypted.
• You can configure the protocol settings using Command Center RX.
Command Center RX User Guide
NOTE
When setting "VNC (RFB)" to [On] in step 2, the default port number is 9062. When
setting "VNC (RFB) over SSL " to [On], the default port number is 9063.
Protocol Settings (page 8-37)

Kyocera ECOSYS P4060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	3.8 s
Print speed (black, normal quality, A3)	30 ppm
Print speed (black, normal quality, A4/US Letter)	60 ppm
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	4
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Storage media	HDD
Processor cores	2
Processor family	NXP QorIQ
Noise level (ready)	32.4 dB
Compatible memory cards	SD, SDHC
Internal storage capacity	328 GB
Sound pressure level (printing)	55.8 dB
Printer fonts	Barcode, Bitmap, PCL, Windows
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	15000 - 30000 pages per month
Replacement cartridges	TK-6330 (32.000 pagina's)
Number of PostScript fonts	136
Page description languages	PCL 6, PDF 1.7, PostScript 3, TIFF, XPS
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Quantity per pack	1 pc(s)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	40 W
Power consumption (printing)	820 W
Power consumption (PowerSave)	1 W
Energy Star Typical Electricity Consumption (TEC)	3.15 kWh/week
Display	LCD
Control type	Touch
Certification	TUV-GS, CE
Product color	Black, Grey
Display diagonal	9 \
Market positioning	Business
Total input capacity	1000 sheets
Maximum input capacity	7150 sheets
Paper tray 1 input capacity	500 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	150 sheets
Envelopes sizes	C5, DL, Monarch
Custom media width	98 - 148 mm
Custom media length	320 - 457 mm
Duplex media weight	60 - 256 g/m²
Paper tray media types	Plain paper
Paper tray media weight	52 - 300 g/m²
Non-ISO print media sizes	Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A3+, A4, A4+, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Banner
Maximum ISO A-series paper size	A3+
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	752 mm
Package width	814 mm
Package height	1109 mm
Package weight	100000 g
Cables included	AC
Included cartridge capacity (black)	16000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	602 mm
Width	665 mm
Height	790 mm
