10-58
Troubleshooting > Clearing Paper Jams
3
Remove any jammed paper.
4
Return the cover to the original position.
5
If the optional side feeder is installed, return the side feeder to
the original position.
Remove any jammed paper in Right Cover 2
(1,500-sheet×2)
1
If the optional side feeder is installed, detach the side feeder.
• Do not reuse jammed papers.
• If the paper tears during removal, be sure to remove any loose scraps of paper from inside the machine.
Scraps of paper left in the machine could cause subsequent jamming.
To Next Page
