Kyocera ECOSYS P4060DN User Manual

2-25
Installing and Setting up the Machine > Network Setup
Network Setup
Configuring the Wired Network
The machine is equipped with network interface, which is compatible with network protocols such as TCP/IP (IPv4),
TCP/IP (IPv6), NetBEUI, and IPSec. It enables network printing on the Windows, Macintosh, UNIX and other platforms.
Set up TCP/IP (IPv4) to connect to the Windows network.
Be sure to connect the network cable before configuring the settings.
Connecting LAN Cable (page 2-7)
For other network settings, refer to the following:
Network (page 8-30)
For other network settings, refer to the following:
Network
(page 8-30)
Configuration Method Description Reference Page
Configuring the Connection
from the Operation Panel
on This Machine
Use Quick Setup Wizard when configuring the
network in a wizard-style screen, without setting
individually in System menu.
Quick Setup Wizard (page 2-
37)
Use Wired Network Settings or Optional Network to
configure the network in details from System menu.
Wired Network Settings
(page 8-35)
Optional Network (page 8-42)
Configuring Connections
on the Web Page
For the equipped network interface, the connection
can be set by using Command Center RX. For the
optional IB-50, the connection can be set by using
the dedicated Web page.
Command Center RX User
Guide
IB-50 Operation Guide
Setting the Connection by
Using the Setup Utility of
IB-50
This is the setup tool included in the CD of IB-50. You
can use it on Windows.
IB-50 Operation Guide
NOTE
When you want to switch to the network interface other than Wired (default) after installing an optional Network
Interface Kit (IB-50) and a Wireless Network Interface Kit (IB-35 or IB-51), select the desired setting on "Primary
Network (Client)".
Primary Network (Client)
(page 8-45)
NOTE
If user login administration is enabled, you can only change the settings by logging in with administrator privileges.
If user login administration is disabled, the user authentication screen appears. Enter a login user name and
password, and select [Login].
The factory default login user name and login password are set as shown below.
Login User Name: 6000
Login Password: 6000

Kyocera ECOSYS P4060DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	3.8 s
Print speed (black, normal quality, A3)	30 ppm
Print speed (black, normal quality, A4/US Letter)	60 ppm
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	4
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Storage media	HDD
Processor cores	2
Processor family	NXP QorIQ
Noise level (ready)	32.4 dB
Compatible memory cards	SD, SDHC
Internal storage capacity	328 GB
Sound pressure level (printing)	55.8 dB
Printer fonts	Barcode, Bitmap, PCL, Windows
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	15000 - 30000 pages per month
Replacement cartridges	TK-6330 (32.000 pagina's)
Number of PostScript fonts	136
Page description languages	PCL 6, PDF 1.7, PostScript 3, TIFF, XPS
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Quantity per pack	1 pc(s)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	40 W
Power consumption (printing)	820 W
Power consumption (PowerSave)	1 W
Energy Star Typical Electricity Consumption (TEC)	3.15 kWh/week
Display	LCD
Control type	Touch
Certification	TUV-GS, CE
Product color	Black, Grey
Display diagonal	9 \
Market positioning	Business
Total input capacity	1000 sheets
Maximum input capacity	7150 sheets
Paper tray 1 input capacity	500 sheets
Maximum number of input trays	5
Multi-Purpose tray input capacity	150 sheets
Envelopes sizes	C5, DL, Monarch
Custom media width	98 - 148 mm
Custom media length	320 - 457 mm
Duplex media weight	60 - 256 g/m²
Paper tray media types	Plain paper
Paper tray media weight	52 - 300 g/m²
Non-ISO print media sizes	Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A3+, A4, A4+, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Banner
Maximum ISO A-series paper size	A3+
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	752 mm
Package width	814 mm
Package height	1109 mm
Package weight	100000 g
Cables included	AC
Included cartridge capacity (black)	16000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	602 mm
Width	665 mm
Height	790 mm
