10-43
Troubleshooting > Clearing Paper Jams
Remove any jammed paper in Cassette 3 and 4
(500-sheet×2)
See the explanation for Cassette 3 below.
1
If the optional side feeder is installed, detach the side feeder.
2
Open Right Cover 2.
3
Remove any jammed paper.
• Do not reuse jammed papers.
• If the paper tears during removal, be sure to remove any loose scraps of paper from inside the machine.
Scraps of paper left in the machine could cause subsequent jamming.
To Next Page
