2GZ/2G1
1-3-4
U030
Checking motor operation
Description
Drives each motor.
Purpose
To check the operation of each motor.
Method
1. Enter the maintenance mode and press the cursor up/down keys to display [U030].
2. Press the cursor right key to display the submenu screen.
3. Press the cursor up/down keys to select the motor to activate.
4. Press the OK key. [Execute] will be displayed and operation will start.
5. To stop operation, press the OK key or the CANCEL key.
U031
Checking switches for paper conveying
Description
Displays the on-off status of each paper detection switch on the paper path.
Purpose
To check if the switches for paper conveying operate correctly.
Method
1. Enter the maintenance mode and press the cursor up/down keys to display [U031].
2. Press the cursor right key to display the submenu screen.
3. Press the cursor up/down keys to select the switch to check.
4. Turn on or off the switch manually to check the switch status. 0: Off 1: On
Maintenance
item No.
Description
>Drive Motors >
[U030]
Submenu display Motor
>>FEED Motor Paper feed motor (PFM)
>>MAIN Motor Drive motor (DM)
>>EJECT MT (FW) Eject motor (EM) rotates forward
>>EJECT MT (REW) Eject motor (EM) rotates in reverse
>>FEED Motor
[030.1]
>Check Switches>
[U031]
Submenu display Switches
>>Check SW F1 Feed switch 1 (FSW1)
SW F2 Feed switch 2 (FSW2)
>>Check SW F3 Feed switch 3 (FSW3)
SW MP MP feed switch (MPFSW)
>>Check SW RES Registration switch (RSW)
SW EJE Eject switch (ESW)
>>Check SW BRA Feedshift switch (FSSW)
SW DUP Duplex paper conveying switch (DUPPCSW)
>>Check SW F1 :1
[031.1] SW F2 :1
To Next Page
