2GZ/2G1-2
1-3-27
Service items Description
Code conversion
ABCDEFGHI J
0123456789
No. Items Description
4 Software jumper switch
information
(hexadecimal)
[First byte/second byte]
First byte
bit 0 = 1: (Fixed)
bit 1 = 0: Overseas,
1: Domestic (Japan)
bit 2, 3 (Not used)
bit 4 = 0: KC, 1: OEM
bit 5 = 0: For Europe, 1: For US
bit 6 = 0: Non MICR mode,
1: MICR mode
bit 7 (Not used)
Second byte:
Displayed in OEM mode only.
5 Tota l pa g e -
6 Toner install information -
7 Parallel I/O information -
8 Serial information 00: Not connected
bit0: Framing error
bit1: Overrun error
bit2: Parity error
9 USB information 00: Not connected
01: Full-Speed
02: Hi-Speed
10 Operation panel lock sta-
tus (displayed only when
locked)
01: Partial lock
02: Full lock
11 NVRAM error (displayed
only when any error has
occurred)
01: ID error
02: Version error
03: Checksum error
04: NVRAM crush error
12 NVRAM download 00: Normal
bit0: Font data
bit1: Host data
bit2: Macro data
bit3: Program data
bit4: Operation panel message data download (file name displayed)
bit5: OEM data
bit6: Web template data (version displayed)
bit7: Error occurred
13 Printable area setting /Top offset/Left offset/Page length/Page width
14 Left offset for each paper
source
/MP tray/Cassette1/Cassette 2/Cassette 3/Cassette 4/Cassette 5/Duplex
(1/600 inches unit)
15 Top offset for each paper
source
/MP tray/Cassette 2/Cassette 3/Cassette 4/Cassette 5/Duplex
(1/600 inches unit)
16 Offset for rotation /Top offset/Left offset/
(1/600 inches unit)
17 Paper cassette life counter /Total counter (large)/Total counter (small)/MP tray/
18 Paper cassette life counter /Cassette 1 total/Cassette 2 total/Cassette 3 total/
19 Paper cassette life counter /Cassette 4 total/
