Detail of event log (EVENT LOG) information
Service items Description
No. Items Description
(1) Engine PWB mask version [Engine mask version/Engine software version]
(2) Operation panel PWB mask ver-
sion
-
(3) BROM version -
(4) Software jumper switch informa-
tion (hexadecimal)
[First byte/Second byte]
First byte
bit 0 = 1: (Fixed)
bit 1 = 0: Overseas, 1: Domestic (Japan)
bit 2, 3 (Not used)
bit 4 = 0: KC, 1: OEM
bit 5 = 0: For Europe, 1: For US
bit 6 = 0: Non MICR mode, 1: MICR mode
bit 7 (Not used)
Second byte:
Displayed in OEM
mode only
(5) Main PWB firmware mask ver-
sion
-
(6) Main PWB firmware release
date
-
(7) Total page counter -
(8) Drum serial number -
(9) Machine serial number -
(10) Paper Jam Log # Count. Event
Remembers 1 to 16 of
occurrence. If the occur-
rence of the previous
paper jam is less than
16, all of the paper jams
are logged. When the
occurrence excessed
16, the oldest occur-
rence is removed.
The total page count
at the time of the
paper jam.
Log code (2 digit,
hexadecimal, 6
categories)
(a) Cause of a
paper jam
(b) Position of
paper jam
(c) Paper source
(d) Paper size
(e) Paper type
(f) Paper exit
Refer to the next
page for the details
of each log code.
