Kyocera FS-9530DN Service Manual

2GZ/2G1-2
1-3-31
Service items Description
No. Items Description
(10)
cont.
(a) Cause of paper jam (Hexadecimal)
04: Cover opened. [00]
05: Memory read ready time-out (secondary paper feed does not start). [4D]
09: Sequence error (3000-sheet paper feeder). [33]
10: No paper feed (cassette 1). [31]
11: No paper feed (cassette 2). [32]
12: No paper feed (cassette 3: paper feeder/3000-sheet paper feeder). [33]
13: No paper feed (cassette 4: paper feeder). [34]
14: No paper feed (MP tray). [42]
15: Jam in horizontal paper conveying section. Paper path sensor 3 (PPSENS3) non-
arrival jam (3000-sheet paper feeder). [33]
16: Jam in horizontal paper conveying section. Paper path sensor 2 (PPSENS2) non-
arrival jam (3000-sheet paper feeder). [33]
17: Jam in horizontal paper conveying section. Paper path sensor 1 (PPSENS1) non-
arrival jam (3000-sheet paper feeder). [33]
18: Jam in vertical paper feed section. [4D]
19: Jam in vertical paper feed section (paper feeder). [43]
20: Jam in MP tray paper conveying section. [48]
21: Multiple sheets in paper feed section. [4D]
22: Multiple sheets in vertical paper conveying section. [4D]
23: Multiple sheets in MP tray paper conveying section. [48]
30: Jam in registration/transfer section. [4D]
40: Jam in fuser section (paper feed from MP tray). [4D]
41: Jam in fuser section (paper feed from cassette 1). [4D]
42: Jam in fuser section (paper feed from cassette 2). [4D]
43: Jam in fuser section (paper feed from cassette 3: paper feeder). [4D]
44: Jam in fuser section (paper feed from cassette 4: paper feeder). [4D]
45: Jam in fuser section (paper feed from 3000-sheet paper feeder). [4D]
46: Jam in fuser section (paper refeed from duplex section). [4D]
50: Jam in eject section. [4D]
52: Jam in feedshift section. [4D]
60: Jam in duplex paper conveying section 1. [4D]
61: Jam in duplex paper conveying section 2. [4D]
80: Jam between the printer and 3000-sheet document finisher. [46]
81: Paper entry sensor (PES) non-arrival jam (3000-sheet document finisher). [46]
Paper entry sensor1/2 (PES1/PES2) non-arrival jam (document finisher). [46]
82: Jam in stapler (3000-sheet document finisher/document finisher). [46]
83: Exit sensor (ESW1) stay jam (3000-sheet document finisher). [46]
Exit sensor (EXS) stay jam (document finisher). [46]
84: Jam in eject section of right sub tray (3000-sheet paper feeder). [46]
85: Jam in eject section of left sub tray (3000-sheet paper feeder). [46]
86: Jam in eject section of internal tray 1 (3000-sheet paper feeder). [46]
87: Jam in eject section of internal tray 2 (3000-sheet paper feeder). [46]
88: Jam in eject section of main tray (3000-sheet paper feeder). [46]
89: Jam in centerfold unit (3000-sheet document finisher). [50]
90: Jam in mailbox (3000-sheet document finisher). [51]
91: Document finisher cover opened. [46]
92: Exit sensor (EXS) non-arrival jam (document finisher). [46]
93: Reverse sensor (REVS) jam (document finisher). [46]
94: Paper entry sensor (PES) stay/remaining jam (document finisher). [46]
95: Paper conveying sensor (PCS) jam (document finisher). [46]
Note:
Values (hexadecimal) within [ ] indicate paper misfeed locations, see next page.
