Kyocera FS-9530DN Service Manual

2GZ/2G1
1-4-5
Feedshift
section
52
Misfeed in feedshift
section
The feedshift switch (FSSW) does not turn on within
specified time of the start of eject motor (EM) reverse
rotation.
1196 ms
During paper switchback operation, the feedshift switch
(FSSW) does not turn off within specified time of the its
turning on.
2313 ms
The feedshift switch (FSSW) does not turn off within
specified time of the registration switch (RSW) turning off.
2243 ms
The feedshift switch (FSSW) does not turn off within
specified time of the registration clutch (RCL) turning on.
2243 ms
Duplex
section
60
Duplex paper convey-
ing section 1
The duplex paper conveying switch (DUPPCSW) does
not turn on within specified time of the feedshift switch
(FSSW) turning on.
2196 ms
The duplex paper conveying switch (DUPPCSW) does
not turn off within specified time of the feedshift switch
(FSSW) turning off.
2196 ms
61
Duplex paper convey-
ing section 2
The feed switch 1 (FSW1) does not turn on within speci-
fied time of the duplex paper conveying switch (DUP-
PCSW) turning on.
1543 ms
The feed switch 1 (FSW1) does not turn off within speci-
fied time of the duplex paper conveying switch (DUP-
PCSW) turning off.
1543 ms
Optional
finisher
80
Jam between the fin-
isher and machine
(3000-sheet document
finisher only)
Paper ejection is not output from the machine to the doc-
ument finisher within specified time of the paper entry
sensor (PES) turning on.
15 s
81
Paper entry sensor non
arrival jam
(3000-sheet document finisher)
The paper entry sensor (PES) is not turned off even if a
specified time has elapsed after the machine eject signal
was received.
1052 ms
The paper entry sensor (PES) is not turned on even if a
specified time has elapsed after the machine eject signal
was received.
1052 ms
The paper entry sensor (PES) does not turn off within
specified time of its turning on.
2313 ms
(Document finisher)
The paper entry sensor (PES) is not turned on even if a
specified time has elapsed after the machine eject signal
was received.
2627 ms
82
Jam in stapler
(3000-sheet document finisher)
The home position is not detected within the specified
time when driving the staple motor.
600 ms
(Document finisher)
The staple home position sensor (STSPS) is not turned
on within the specified time when driving the staple motor
(STM).
1000 ms
Section Description Conditions Specified time

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
