Kyocera FS-9530DN Service Manual

2GZ/2G1
1-4-6
Optional
finisher
83
Exit sensor stay jam
(3000-sheet document finisher)
Eject switch 1 (ESW1) is not turned off within specified
time of its turning on.
1182 ms
(Document finisher)
In the straight mode, the exit sensor (EXS) is not turned
off within specified time of its turning on.
1680 ms
(Document finisher)
In the offset or staple mode, the exit sensor (EXS) is not
turned off within specified time of its turning on.
5375 ms
84
Jam in eject section of
right sub tray (3000-
sheet document fin-
isher only)
Eject switch 2 (ESW2) is not turned off even if a specified
time has elapsed after the machine eject signal was
received.
1209 ms
Eject switch 2 (ESW2) is not turned on even if a specified
time has elapsed after the machine eject signal was
received.
1209 ms
Eject switch 2 (ESW2) is not turned off within specified
time of its turning on.
2313 ms
85
Jam in eject section of
left sub tray (3000-
sheet document fin-
isher only)
Eject switch 3 (ESW3) does not turn off within specified
time of paper entry sensor (PES) turning on.
1426 ms
Eject switch 3 (ESW3) does not turn on within specified
time of paper entry sensor (PES) turning on.
1426 ms
Eject switch 3 (ESW3) is not turned off within specified
time of its turning on.
2313 ms
86
Jam in eject section of
internal tray 1 (3000-
sheet document fin-
isher only)
Internal tray entry sensor 1 (ITPES1) is not turned on
even if a specified time has elapsed after the eject signal
was received.
2070 ms
87
Jam in eject section of
internal tray 2 (3000-
sheet document fin-
isher only)
Internal tray entry sensor 2 (ITPES2) does not turn on
within specified time of internal tray entry sensor 1
(ITPES1) turning on.
1322 ms
Internal tray entry sensor 2 (ITPES2) does not turn off
within specified time of internal tray entry sensor 1
(ITPES1) turning off.
676 ms
88
Jam in eject section of
main tray (3000-sheet
document finisher only)
Eject switch 1 (ESW1) is not turned on within specified
time.
1324 ms
Side registration home position sensor 1 (SRHPS1) is not
turned off within specified time of its turning on.
500 ms
Side registration home position sensor 2 (SRHPS2) is not
turned off within specified time of its turning on.
500 ms
The paper conveying belt detection sensor (PCBDS) is
not turned off within specified time.
2000 ms
Section Description Conditions Specified time

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
