Kyocera FS-9530DN Service Manual

2GZ/2G1-2
1-4-7
Optional
finisher
89
Jam in centerfold unit
(3000-sheet document
finisher only)
The centerfold paper entry sensor (CPES) does not turn
off within specified time of centerfold paper detection sen-
sor (CPDS) turning on.
1370 ms
The centerfold paper entry sensor (CPES) does not turn
on within specified time of centerfold paper detection sen-
sor (CPDS) turning on.
1370 ms
The centerfold paper entry sensor (CPES) is not turned
off within specified time of its turning on.
2313 ms
The centerfold eject switch (CESW) is not turned on
within specified time.
3040 ms
The centerfold eject switch (CESW) is not turned off
within specified time of its turning on.
4213 ms
Centerfold side registration sensor 1 (CSRS1) is not
turned on within specified time.
600 ms
Centerfold side registration sensor 2 (CSRS2) is not
turned on within specified time.
600 ms
The home position is not detected within the specified
time after driving the centerfold staple motor (CSTM).
1000 ms
The centerfold paper detection sensor (CPDS) is not
turned off within specified time.
3504 ms
The centerfold paper detection sensor (CPDS) is not
turned on within specified time.
3504 ms
The centerfold paper detection sensor (CPDS) is not
turned off within specified time of its turning on.
2313 ms
90
Jam in mailbox
(3000-sheet document
finisher only)
The mail paper entry switch (MPESW) is not turned on
within specified time.
1017 ms
The mail paper entry switch (MPESW) is not turned off
within specified time of its turning on.
2313 ms
The tray eject sensor (TEJS) does not turn on within
specified time of mail paper entry switch (MPESW) turn-
ing on.
Tray 1 to 4
2026 ms
Tray 5 to 7
1148 ms
The tray eject sensor (TEJS) is not turned off within spec-
ified time of its turning on.
2313 ms
91
Finisher cover open
(3000-sheet document finisher)
The front cover, top cover or right sub tray is opened
when starting the finisher operation.
The centerfold unit top cover is opened when starting the
centerfold operation.
The mailbox cover is opened when starting the operation.
-
(Document finisher)
The finisher cover becomes open during paper is run-
ning.
Paper is remaining in paths at power on.
-
92
Exit sensor non-arrival
jam (document finisher
only)
In the straight mode, the exit sensor (EXS) is not turned
on even if a specified time has elapsed after the paper
entry sensor (PES) was turned on.
1770 ms
Section Description Conditions Specified time

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
