Kyocera FS-9530DN Service Manual

2GZ/2G1-2
1-4-15
(24)
A paper jam in
optional document
finisher is indicated
during printing (fin-
isher stapler jam).
Jam code 82
Defective staple home posi-
tion sensor.
With 5 V DC present at YC22-6 on the finisher main PWB, check if
YC22-5 on the finisher main PWB remains low or high when the
staple home position sensor is turned on and off. If it does,
replace the staple home position sensor.
(25)
A paper jam in
optional document
finisher is indicated
during printing (eject
sensor stay jam).
Jam code 83
3000-sheet document finisher
Defective eject switch 1. With 5 V DC present at YC16-A7 on the finisher main PWB, check
if YC16-A6 on the finisher main PWB remains low or high when
the eject switch 1 is turned on and off. If it does, replace the eject
switch 1.
Document finisher
Defective eject sensor. With 5 V DC present at CN5-4 on the finisher main PWB, check if
CN5-6 on the finisher main PWB remains low or high when the
eject sensor is turned on and off. If it does, replace the eject sen-
sor.
Check if the paper convey-
ing motor malfunctions.
Check and remedy.
Check if the eject roller and
eject pulley contact each
other.
Check and remedy.
Check if the eject guide is
deformed.
Check and remedy.
Defective finisher main
PWB.
Replace the finisher main PWB and check for correct operation.
(26)
A paper jam in
optional document
finisher is indicated
during printing (sub
tray eject jam).
Jam code 84
Defective eject switch 2. With 5 V DC present at YC19-3 on the finisher main PWB, check if
YC19-2 on the finisher main PWB remains low or high when the
eject switch 2 is turned on and off. If it does, replace the eject
switch 2.
(27)
A paper jam in
optional document
finisher is indicated
during printing (sub
tray eject jam).
Jam code 85
Defective eject switch 3. With 5 V DC present at YC16-A4 on the finisher main PWB, check
if YC16-A3 on the finisher main PWB remains low or high when
the eject switch 3 is turned on and off. If it does, replace the eject
switch 3.
(28)
A paper jam in
optional document
finisher is indicated
during printing (inter-
nal tray paper entry
sensor 1 jam).
Jam code 86
Defective internal tray
paper entry sensor 1.
With 5 V DC present at YC11-1 on the internal tray PWB, check if
YC11-2 on the internal tray PWB remains low or high when the
internal tray paper entry sensor 1 is turned on and off. If it does,
replace the internal tray paper entry sensor 1.
Problem
Causes/check procedures Corrective measures

Kyocera FS-9530DN Specifications

General

Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	3.5 s
Print speed (black, normal quality, A3)	26 ppm
Print speed (black, normal quality, A4/US Letter)	51 ppm
Memory type	DDR
Memory slots	1
Processor model	750FL
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	640 MB
Sound power level (standby)	51 dB
Sound pressure level (printing)	70 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	200 sheets
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv4)	TCP/IP, IPX/SPX, AppleTalk, NetBEUI
Printing colors	Black
Maximum duty cycle	300000 pages per month
Page description languages	PCL 5e, PCL 6, PCL XL
Current rating	11.4 A
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	180 W
Power consumption (printing)	900 W
Power consumption (PowerSave)	4.5 W
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 95, Windows 98, Windows 98SE, Windows ME, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Product color	White
Networking features	Fast Ethernet

Weight and Dimensions

Dimensions (WxDxH)	599 x 646 x 615 mm
