Kyocera FS-C2026MFP Service Manual

2KW/2KX
1-4-21
5304 Broken cleaning lamp Y
wire
When the cleaning lamp Y is
driven, the lamp over-current
detection signal is detected
continuously for 10 times (1 s)
at 100 ms intervals.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Drum unit Y and Drum relay PWB (YC5)
Drum relay PWB (YC1) and engine PWB
(YC34)
Defective cleaning
lamp Y.
Replace the drum unit Y. (see page 1-5-20).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-26).
6000 Broken fuser heater wire
The detected temperature of
fuser thermistor does not rise
1C/1.8F after the fuser
heater has been turned on
continuously for 10 s in warm-
ing up.
The fuser temperature does
not reach 100C/212F after
the fuser heater has been
turned on continuously for
30 s in warming up.
The detected temperature of
fuser thermistor does not
reach the specified tempera-
ture (ready indication temper-
ature) after the fuser heater
has been turned on continu-
ously for 60 s in warming up.
The detected temperature of
fuser thermistor does not rise
1C/1.8F after the fuser
heater has been turned on
continuously for 10 s during
printing.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Fuser heater and power source PWB
(YC102)
Fuser unit and eject PWB (YC3)
Eject PWB (YC1) and engine PWB (YC19)
Fuser thermostat
triggered.
Reinsert the fuser unit (see page 1-5-25).
Broken fuser
heater wire.
Replace the fuser unit (see page 1-5-25).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-26).
6020 Abnormally high fuser
thermistor temperature
The fuser thermistor detects a
temperature higher than
240C/464F.
By the activation of the high
temperature error detection
circuit (230C/446F or more)
of fuser thermistor, the illumi-
nation of fuser heater was
forcibly turned off and 10 s
has elapsed.
Shorted fuser
thermistor.
Replace the fuser unit (see page 1-5-25).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-26).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
