Kyocera FS-C2026MFP Service Manual

2KW/2KX
1-4-47
(2) Table of general classification
Error code Description
U00000 No response or busy after the set number of redials.
U00100 Transmission was interrupted by a press of the stop/clear key.
U00200 Reception was interrupted by a press of the stop/clear key.
U00300 Recording paper on the destination unit has run out during transmission.
U004XX A connection was made but interrupted during handshake with the receiver unit (refer to
1-4-49 U004XX error code table).
U006XX Communication was interrupted because of a machine problem (refer to 1-4-49 U006XX
error code table).
U00700 Communication was interrupted because of a problem in the destination unit.
U008XX A page transmission error occurred in G3 mode (refer to 1-4-49 U008XX error code
table).
U009XX A page reception error occurred in G3 mode (refer to 1-4-49 U009XX error code table).
U010XX Transmission in G3 mode was interrupted by a signal error (refer to 1-4-50 U010XX error
code table).
U011XX Reception in G3 mode was interrupted by a signal error (refer to 1-4-51 U011XX error
code table).
U01400 An invalid one-touch key was specified during communication.
U01500 A communication error occurred when calling in V.8 mode.
U01600 A communication error occurred when called in V.8 mode.
U017XX A communication error occurred before starting T.30 protocol during transmission in V.34
mode (refer to 1-4-52 U017XX error code table).
U018XX A communication error occurred before starting T.30 protocol during reception in V.34
mode (refer to 1-4-52 U018XX error code table).
U03000 No document was present in the destination unit when polling reception started.
U03200 In interoffice subaddress-based bulletin board reception, data was not stored in the box
specified by the destination unit.
U03300 In polling reception from a unit of our make, operation was interrupted due to a mismatch
in permit ID or telephone number. Or, in interoffice subaddress-based bulletin board
reception, operation was interrupted due to a mismatch in permit ID or telephone num-
ber.
U03400 Polling reception was interrupted because of a mismatch in individual numbers (destina-
tion unit is either of our make or by another manufacturer).
U03500 In interoffice subaddress-based bulletin board reception, the specified Subaddress confi-
dential box number was not registered in the destination unit.
U03600 An interoffice subaddress-based bulletin board reception was interrupted because of a
mismatch in the specified subaddress confidential box number.
U03700 Interoffice subaddress-based bulletin board reception failed because the destination unit
had no subaddress-based bulletin board transmission capability, or data was not stored
in any subaddress confidential box in the destination unit.
U04000 In interoffice subaddress-based transmission mode, the specified subaddress box num-
ber was not registered in the destination unit.

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
