Kyocera FS-C2026MFP

2KW/2KX
1-5-63
(2) Detaching and refitting the operation panel
Procedure
1. Release four hooks and then remove
the operation panel.
2. Remove the FFC from connector.
3. Check or replace the operation panel
and refit all the removed parts.
Figure 1-5-96
Operation panel
Connector
Hook
Hook
Hook
Hook
FFC
