2KW/2KX
1-2-8
1-2-3 Installing the expansion memory (option)
Procedure
1. Turn off the main power switch.
Caution: Do not insert or remove
expansion memory while machine
power is on.
Doing so may cause damage to the
machine and the expansion memory.
2. Remove the memory cover.
Figure 1-2-12
3. Unlock the lock and then open the fan
holder.
Figure 1-2-13
Memory cover
Lock
Fan holder
To Next Page
