Kyocera FS-C2026MFP Service Manual

2KW/2KX
1-4-37
(11)
Registration clutch
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Registration clutch and engine PWB (YC3)
2. Defective clutch. Replace the registration clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(12)
Middle clutch does
not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Middle clutch and engine PWB (YC3)
2. Defective clutch. Replace the middle clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(13)
MP solenoid does
not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP solenoid and engine PWB (YC4)
2. Defective solenoid. Replace the MP solenoid.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(14)
The message
requesting paper to
be loaded is shown
when paper is
present on the cas-
sette.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Cassette PWB (YC1) and engine PWB (YC21)
2. Deformed actuator of
the paper sensor.
Check visually and replace if necessary.
3. Defective paper sen-
sor.
Replace the cassette PWB.
4. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(15)
The message
requesting paper to
be loaded is shown
when paper is
present on the MP
tray.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP paper sensor and engine PWB (YC16)
2. Deformed actuator of
the MP paper sensor.
Check visually and replace if necessary.
3. Defective MP paper
sensor.
Replace the MP paper sensor.
4. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
(16)
The size of paper
on the cassette is
not displayed cor-
rectly.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Cassette size switch and engine PWB (YC17)
2. Defective cassette
size switch.
Replace the cassette size switch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-26).
Problem Causes Check procedures/corrective measures

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
