Kyocera FS-C2026MFP Service Manual

2KW/2KX
1-4-39
(22)
DP switchback
solenoid does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
DP switchback solenoid and DP drive PWB (YC5)
DP drive PWB (YC8) and main PWB (YC32)
2. Defective solenoid. Replace the DP switchback solenoid.
3. Defective PWB. Replace the DP drive PWB or main PWB and check for
correct operation (see page 1-5-60, 1-5-29).
(23)
An original jams
when the main
power switch is
turned on.
1. A piece of paper torn
from an original is
caught around the
DP timing sensor.
Check visually and remove it, if any.
2. Defective DP timing
sensor.
Replace the DP timing sensor.
(24)
A message indicat-
ing cover open is
displayed when the
DP top cover is
closed.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
DP open/close sensor and DP drive PWB (YC2)
DP drive PWB (YC8) and main PWB (YC32)
2. Defective DP open/
close sensor.
Replace the DP open/close sensor.
Problem Causes Check procedures/corrective measures

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
