2KW/2KX
1-5-30
6. Remove the screw and then remove the
fuser wire cover.
Figure 1-5-43
7. Remove five screws and then remove
the controller shield.
Figure 1-5-44
Screw
Fuser wire cover
Controller
shield
Screw
Screw
Screw
Screw
Screw
