2KW/2KX
1-5-38
7. Remove five screws and then remove
drum/developing drive unit.
8. Check or replace the drum/developing
drive unit and refit all the removed
parts.
Figure 1-5-57
Drum/Developing
drive unit
Screw
Screw
Screw
Screw
Screw
