Kyocera FS-C2026MFP Service Manual

2KW/2KX
2-3-2
Connector Pin Signal I/O Voltage Description
YC101 1 LIVE I 120 V AC
220-240 V AC
AC power input
Connected to
AC inlet and
main power
switch
2 NEUTRAL I 120 V AC
220-240 V AC
AC power input
YC102 1 NEUTRAL O 120 V AC/0 V
220-240 V AC/0 V
FH: On/Off
Connected to
fuser heater
2 LIVE O 120 V AC
220-240 V AC
AC power to FH
YC103 1 +24V1 O 24 V DC 24 V DC power to RYPWB
Connected to
relay PWB
2 GND - - Ground
3 GND - - Ground
4 GND - - Ground
5 GND - - Ground
6 +24V2 O 24 V DC 24 V DC power to RYPWB (via ILSW)
7 +24V2 O 24 V DC 24 V DC power to RYPWB (via ILSW)
8 +24V2 O 24 V DC 24 V DC power to RYPWB (via ILSW)
9 +24V2 O 24 V DC 24 V DC power to RYPWB (via ILSW)
10 PSSLEEPN I 0/3.3 V DC Sleep mode signal: On/Off
11 ZCROSS O 0/3.3 V DC (pulse) Zero-cross signal
12 RELAY
I
0/3.3 V DC Relay signal
13 HEATRE1 I 0/3.3 V DC FH: On/Off
YC104 1 +24V1 O 24 V DC 24 V DC power to ILSW
Connected to
interlock
switch
2N.C -- Not used
3 +24V2 I 24 V DC 24 V DC power from ILSW
YC105 1 +24V1 O 24 V DC 24 V DC power to MPWB
Connected to
main PWB
2 GND - - Ground
3 GND - - Ground
4 +5V1 O 5 V DC 5 V DC power to MPWB

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
