Kyocera FS-C2026MFP - Page 271

2KW/2KX
2-3-7
YC11 25 BCACNT O PWM Developing AC bias control voltage
(Cyan)
Connected to
high voltage
PWB
26 BMACNT O PWM Developing AC bias control voltage
(Magenta)
27 BYACNT O PWM Developing AC bias control voltage
(Yellow)
28 HVCLKK O 0/3.3 V DC (pulse) Developing bias clock signal (Black)
29 BCSCNT O PWM Developing sleeve bias control voltage
(Cyan)
30 HVCLKM O 0/3.3 V DC (pulse) Developing bias clock signal (Magenta)
31 GND - - Ground
32 GND - - Ground
YC13 1MOTREV
(GND)
- - Ground
Connected to
drum motor
2 MOTRDYN I 0/3.3 V DC DRM ready signal
3 SPEEDSEL O 0/3.3 V DC DRM speed selection signal
4 MOTCLK O 0/3.3 V DC (pulse) DRM clock signal
5 MOTEN O 0/3.3 V DC DRM: On/Off
6 GND - - Ground
7 +24V3 O 24 V DC 24 V DC power to DRM
YC14 1 +24V3 O 24 V DC 24 V DC power to DEVM
Connected to
developing
motor
2 GND - - Ground
3 DLPMOTREN O 0/3.3 V DC DEVM: On/Off
4 DLPMOTCLK O 0/3.3 V DC (pulse) DEVM clock signal
5DLPMOT
RDYN
I 0/3.3 V DC DEVM ready signal
6 MOTREV O 0/3.3 V DC DEVM drive switch signal
YC15 1 IMAMOT
RDYN
I 0/3.3 V DC FUM ready signal
Connected to
fuser motor
2 IMAMOTCLK O 0/3.3 V DC (pulse) FUM clock signal
3 IMAMOTREN O 0/3.3 V DC FUM: On/Off
4 GND - - Ground
5 +24V3 O 24 V DC 24 V DC power to FUM
YC16 1 +3.3V2_LED1 O 3.3 V DC 3.3 V DC power to MPPS
Connected to
MP paper
sensor
2 GND - - Ground
3 MPFPAP I 0/3.3 V DC MPPS: On/Off
Connector Pin Signal I/O Voltage Description
