2KW/2KX
2-3-9
YC27 1 LMOTDRN O 0/24 V DC LM: On/Off
Connected to
lift motor
2 GND - - Ground
YC28 1 +24V1 O 24 V DC 24 V DC power to CFM
Connected to
container fan
motor
2 TCONTFAN
DRN
O 0/12/24 V DC CFM: Full speed/Half speed/Off
YC29 1 +24V1 O 24 V DC 24 V DC power to LFM
Connected to
left fan motor
2 LFANDRN O 0/12/24 V DC LFM: Full speed/Half speed/Off
YC30 1 TCONTN O 0/3.3 V DC TTSW: On/Off
Connected to
top tray
switch
2 GND - - Ground
YC31 1 GND - - Ground
Connected to
laser scanner
unit KM
2 VREFK O Analog APCPWB-K laser power standard voltage
3 LONBKN O 0/3.3 V DC APCPWB-K sample/hold signal
4 ENBKN O 0/3.3 V DC APCPWB-K laser enable signal
5 PDKN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
6 GND - - Ground
7 VREFM O Analog APCPWB-M laser power standard voltage
8 LONBMN O 0/3.3 V DC APCPWB-M sample/hold signal
9 ENBMN O 0/3.3 V DC APCPWB-M laser enable signal
10 PDMN I 0/3.3 V DC (pulse) Horizontal synchronizing signal
11 LSUTHERMM I Analog ITEMS detection voltage
12 POLCLK1 O 0/3.3 V DC (pulse) PM-KM clock signal
13 POLRDYN1 I 0/3.3 V DC PM-KM ready signal
14 POLONN1 O 0/3.3 V DC PM-KM: On/Off
15 GND - - Ground
16 +24V3 O 24 V DC 24 V DC power to PM-KM
17 N.C. - - Not used
18 N.C. - - Not used
Connector Pin Signal I/O Voltage Description
