2KW/2KX
2-3-25
YC8 1 +3.3V2 I 3.3 V DC 3.3 V DC power from MPWB
Connected to
main PWB
2 GND - - Ground
3 TIMSWN O 0/3.3 V DC DPTS: On/Off
4 ORGSWN O 0/3.3 V DC DPOS: On/Off
5 OPSWN O 0/3.3 V DC DPOCS: On/Off
6 DPDETN O 0/3.3 V DC DP set signal
7 RELSOLN I 0/24 V DC DPPRSOL: On (Release)/Off
8 PRESOLN I 0/24 V DC DPPRSOL: On (Press)/Off
9 REVSOL I 0/24 V DC DPSBSOL: On/Off
10 FEEDCL I 0/24 V DC DPPFCL: On/Off
Connector Pin Signal I/O Voltage Description
