Kyocera FS-C2026MFP Service Manual

2KW/2KX
1-3-3
Fax
U620 Setting the remote switching mode One
U625 Setting the transmission system 1
Setting the auto redialing interval
Setting the number of times of auto redialing
3 (120 V)
2 (220-240 V)
2 (120 V)
3 (220-240 V)
U630 Setting communication control 1
Setting the communication starting speed
Setting the reception speed
Setting the waiting period to prevent echo problems at the
sender
Setting the waiting period to prevent echo problems at the
receiver
14400bps/V17
14400bps
300
75
U631 Setting communication control 2
Setting ECM transmission
Setting ECM reception
Setting the frequency of the CED signal
On
On
2100
U632 Setting communication control 3
Setting the DIS signal to 4 bytes
Setting the CNG detection times in the fax/telephone auto
select mode
Off
2Time
U633 Setting communication control 4
Enabling/disabling V.34 communication
Setting the number of times of DIS signal reception
Setting the number of times of DIS signal reception
Setting the reference for RTN signal output
On
On
Once
15%
U634 Setting communication control 5 0
U640 Setting communication time 1
Setting the one-shot detection time for remote switching
Setting the continuous detection time for remote switching
7
80
U641 Setting communication time 2
Setting the T0 time-out time
Setting the T1 time-out time
Setting the T2 time-out time
Setting the Ta time-out time
Setting the Tb1 time-out time
Setting the Tb2 time-out time
Setting the Tc time-out time
Setting the Td time-out time
56
36
69
30
20
80
60
9 (120 V)
6 (220-240 V)
U650 Setting modem 1
Setting the G3 transmission cable equalizer
Setting the G3 reception cable equalizer
Setting the modem detection level
0dB
0dB
-43dBm
Section
Item
No.
Content of maintenance item
Initial
setting

Kyocera FS-C2026MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Total output capacity	- sheets
Maximum input capacity	50 sheets
Internal memory	768 MB
Processor family	PowerPC
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	50 dB
Dimensions (WxDxH)	514 x 550 x 580 mm
Power requirements	AC 220 - 240 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Maximum internal memory	1.75 GB
Color all-in-one functions	copy, print
Compatible operating systems	Windows, Mac OS X 10.2 +, Unix, Linux
Maximum print size	216 x 356 mm
Paper tray media types	Envelopes, Plain paper
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Certification	TÜV/GS, CE
Maximum duty cycle	65000 pages per month
Grayscale levels	256
Image formats supported	JPG, TIF
Sustainability certificates	ENERGY STAR
Market positioning	Business
