Appendix C: Specifications
Electrical Data
Catalog Number
Typical Startup -
Operating Current
Electrical Circuit
Requirements
1
3034xxx01
3 A
115 V, 60 Hz, 12 A
3034xxx21
3 A
100 V, 50/60 Hz, 12 A
3034xxx-11, 31, 41, 51, 61, 71
1.5 A
230 V, 50/60 Hz, 6 A
3036xxx01
5 A
115 V, 60 Hz, 12 A
3036xxx21
5 A
100 V, 50/60 Hz, 12 A
3036xxx-11, 31, 41, 51, 61, 71
2.5 A
230 V, 50/60 Hz, 6 A
Motor Specifications
Cabinet
Electrical Requirements
All Cabinets, all
Voltages
1/2 H.P. Electronically Commutated Motor (ECM)
120-277 VAC – 50/60 Hz,
Full Torque – 42 Oz.-Ft (3.56 N-M)
7.7 Full Load Amps @115VAC
4.3 Full Load Amps @230VAC
Automatic Thermal Protection
1 Electrical Requirements, ‘V’ = VAC (Voltage with alternating current), ‘A’ = Amperes
