Appendix E: Quick Chart
Model
30348_
30368_
Type
B2
B2
Cabinet Size (Feet)
4’
6’
Sash Opening (inches)
8
8
Starting Serial Number
1
1905_
1905_
Nominal Avg. Downflow (FPM)
55+/-5
55+/-5
Nominal Average Inflow (FPM)
105+/-5
105+/-5
Supply HEPA Data
Labconco Catalog Number
3838401
3838403
Exhaust HEPA Data
Labconco Catalog Number
3438501
3438503
Concurrent Balance Values
2
Traverse Exhaust Volume (CFM)
852
1265
Differential Pressure (in. H
2
0)
1.8
2.2
Motor/Blower Data
Labconco Catalog Number
3
3331104
3331105
Motor HP
1/2
1/2
LED Lamp/UV Lamp Data
LED Lamps (2 each)
4
KT-LED 15T8-48GC-840-D
KT-LED 32T8-72GC-840-D
Color (
o
K)
4000
4000
Lumens
1850
3200
Glass Type
Frosted
Frosted
UV Lamp
G30T8
G30T8
1. The primary serial tag is on the lower right edge of the front dress panel. The secondary
serial tag is located on the front of the electronics module on the top right side of the
cabinet. The first two digits of the serial number are the year of production; the next two are
the month. The next 5 digits are the sequence of production, and the letter following the
serial number is the revision level of the cabinet.
2. These values equal the Concurrent Balance Values (CVB) published by National Sanitation
Foundation International (NSF).
3. Each motor must be programmed by Labconco for the appropriate width cabinet.
4. THIS PRODUCT USES DIRECT DRIVE T8 LED LAMPS INSTEAD OF FLUORESCENT
LAMPS. THERE IS NO BALLAST; LINE VOLTAGE IS SUPPLIED TO THE LAMP
SOCKETS.
DO NOT INSTALL FLUORESCENT LAMPS!
FOR REPLACEMENT LED LAMPS, CONTACT THE PRODUCT SERVICE
DEPARTMENT AT (800) 821-5525 or +1 (816) 333-8811.
