18.3 Lengthways settee (Kosmo
series)
On the vehicles with lengthways settee (Kosmo series),
it is necessary to perform the operation described
below to obtain an additional passenger seat.
Turn the plane (a) and the plane (b).
Fit the backrest (c) and secure it with the stop (d).
Position the cushions as shown in picture.
18 - SETTEES
USER’S GUIDE
101
a
b
c
d
Left side of living area
Left side of living area
g
h
Left side of living area
e
f
Left side of living area
Right side of living area
Direction of travel
g
h
e
f
The operation can be carried out both on the left
and the right settee.
NOTE
