16.4 Shower cab (Kosmo Compact 5,
Compact 9)
The Kosmo Compact 5 and Compact 9 models have
been provided with a system that allows them to have a
separated shower cabin according to the following
instructions:
Release the catch (a) (press to unlock) and rotate the
panel (b).
Release the catch (c) and rotate the panel (d).
16 - WASHROOM
88
USER’S GUIDE
a
b
c
d
