18.1 "L"-shaped settee
On the vehicles with "L" shaped settee, it is necessary
to perform the operation described below to obtain an
additional passenger seat.
"L"-shaped settee - A type
Remove the cushion (a).
Lower the tilting piece (b).
"L"-shaped settee - B type
Remove the cushion (a).
Remove the plane (b).
18 - SETTEES
USER’S GUIDE
99
a
b
a
b
During travel, the plane (b) must be stored in a
closed compartment.
WARNING
