LAIKA Kosmo Compact 9 - Night Conversion (Optional); Kosmo Compact 5

In some models it is possible to transform the dinette
into a temporary bed (optional), for one or two persons.
To obtain the plane of the bed, it may be necessary to
lower the table and/or use mobile supports, fold-down
plans, etc. The bed is then completed using the
cushions of the sofas and additional cushions supplied.
19.1 Kosmo Compact 5
To convert the dinette into a bed proceed as follows.
Slide the table top (a) together with the support foot
(b).
Lower the table.
Position the cushions as shown in picture.
19 - NIGHT CONVERSION (OPTIONAL)
USER’S GUIDE
103
In some models it is not possible to transform the
dinette into a bed.
NOTE
The bed obtained from the transformation of the
dinette, while representing a valid solution, cannot
provide the comfort of a bed with a real mattress.
NOTE
c
d
e
Additional cushion
f
c
d
e
f
a
b
b
