7.4 Other components
External 230 V socket
Insert the plug into the socket as shown in the picture.
To remove the plug from the socket, hold the lever (c)
while pulling the plug.
Main circuit breaker: 230 V switch
Located in the vehicle interior, in correspondence with
the external 230 V socket.
Battery master switch
If your vehicle is not going to be in use for a long time,
always disconnect the auxiliary battery by means of
lever (e), located near the 12 V distribution control unit.
Internal temperature sensor
The internal temperature sensor is usually installed next
to the control panel or on the side of the piece of
furniture between the cab and the living quarters.
External temperature sensor
The external temperature sensor is below the floor in
the front right area of the vehicle.
Truma system temperature sensor
Sensor usually installed next to the control panel,
required for the operation of the Truma heating system.
7 - ELECTRIC SYSTEM (ECOVIP - KREOS)
USER’S GUIDE
39
A type B type
d
c
d
It is advisable to routinely check that the circuit
breaker is working properly, by pressing the button
(d).
WARNING
e
