17.3 Table - C type
The table top can slide in four directions.
Slide the table top pressing the unlock lever (a)
positioned under the table top.
The table top can be closed like a book: lift part (b) and
push the support forward (c).
17.4 Table - D type
To lower the table (support position for the bed)
Press the button (a) to fold the table leg.
Lift the table to release it from the upper guide (b).
Hook the table to the lower guide (c).
17.5 Tables with telescopic leg
(optional)
To lower the table, rotate the handle (a) 180 degrees,
then push the table to the desired position. Move back
the handle to its original position to lock the table.
17 - INTERNAL COMPONENTS
90
USER’S GUIDE
b
c
a
a
a
b
c
