Fresh water tank refilling function
This function is used during the fresh water tank
refilling, and shows the water level during refilling.
To activate this function, press for more than two
seconds on button (3) until the "water fill" screen
appears.
The control panel beeps in order to warn that tank is
getting filled: one short beep at 75% level, two short
beeps at 85% level a one long beep at 100% level.
Minimum voltage control (battery protection)
The electronic battery protection device disconnects
the 12 V users when auxiliary battery reaches 10 V and
disables: pump, lights, awning light, RH output, AUX
output, 12 V sockets.
Symbol (22) is the visual alarm signal.
It is possible to connect all users for one more minute
by pressing the ON/OFF button (1).
The control panel automatically turns off with a voltage
lower than 9.5 V.
Users are automatically reconnected with a voltage
higher than 13.5 V.
This device doesn’t control the 12 V users connected
directly to the auxiliary battery B2.
Setting
To enter the set mode, press the button (4) for more
than two seconds.
Select, by pushing the arrow keys (2) and (3), the
setting menu you want to operate and then confirm by
pushing the button (4):
• By selecting “CLOCK” you operate the menu to set
only the parameters clock and alarm clock.
• By selecting “DISPLAY” you operate the menu to set
the display parameters.
• By selecting “SETTING” you operate the menu to set
the system parameters.
• By selecting “ADJUST” you operate the menu to set
the temperature and battery parameters.
• By selecting “SW VERSION” you operate the menu to
view the connected CBE devices’ software versions.
By using the arrow keys (2) and (3) you can modify the
setting of the parameters. Confirm the setting by
pushing the button (4), you then go automatically to
next parameter.
To abandon programming and save changes, select
“EXIT” and then choose to save or not save changes.
9 - CONTROL PANEL
USER’S GUIDE
53
Refer to the producer's handbook for further infor-
mation on the control panel.
NOTE
