Oven without grill (A type)
a) Hatch for door blocking.
b) Oven burner knob. To turn on press and turn towards
left.
c) Oven light switch.
Oven without grill (B type)
a) Oven burner knob. To turn on press and turn towards
left.
Oven without grill (C type)
a) Oven burner knob. To turn on press and turn towards
left.
b) Ignition button.
c) Oven light switch.
Oven with grill
a) Oven burner knob.
b) Ignition button.
c) Oven light switch.
d) Heat protection plate.
12 - GAS SYSTEM
68
USER’S GUIDE
a
c
b
d
When using the grill, extract the heat protection
plate (d) and leave the oven door open.
WARNING
c
a
b
c
a
b
a
