Kreos 5009, 5010
From inside the garage it is possible to reach the
drainage tap (a) and to the probes (b).
Kreos 7009, 7012
From inside the garage it is possible to have access to
the drainage switch (a) and to the probes (b).
Kreos 8002, 8012
From inside the garage you can reach the switches (a)
for the waste water tanks drainage. The drains of the
two tanks converge in a single pipe.
To access the tanks probes, dismantle the plates (b)
located under the floor on both sides, near the rear
axle.
14 - WATER SYSTEM (ECOVIP - KREOS)
80
USER’S GUIDE
a
b
a
b
b
Both tanks are equipped with probes for level
signalling on the control panel. As the tanks inter-
communicate, it is not necessary to drain the tanks
when only one of the tanks is full.
NOTE
b
